Lexicon RV-6

LEXRV6AM

Immersive Surround Sound Receiver

The RV-6 Immersive Surround Sound Receiver takes your private cinema experience to new heights. With Dolby ATMOS and DTS:X 3D surround sound processing, Dirac room EQ, Logic7 Immersion, and plenty of responsive class A/B power; the RV-6 delivers a sensory rich experience.

Find a Dealer

RV-6

Everything you need - Done right

The Lexicon RV-6 was designed to ensure that the most important components of a premium AV system were executed with maximum effectiveness. Superfluous connections and features were eliminated and resources focused to maintain best in class audio and video signal integrity and processing, as well as uncompromised amplification on all channels, all of the time; even with the most demanding program material. The video and audio stages are designed for current and upcoming technologies. HDMI2.0a with HDCP2.2 4K “Ultra HD” and 3D video capability are built in as well as Dolby Vision compatibility.

An audiophile grade 24Bit /192kHz DAC, Dirac room equalization, exceptional dynamics and low distortion ensure pristine sound for music and movies. The Harman proprietary Logic 7 Immersion™ up mixer allows content to envelop the listener with a rich and natural three dimensional sound. Flexible configuration, Spotify Connect, and a zone 2 with audio, 4K video, IR control, triggers and power option, make the RV6 and RV-9 an excellent choice for a broad range of applications.

  • Highlights & Specs
  • What's in the box?
  • Documents & Downloads

Lexicon RV-6 Highlights

  • Logic7 Immersion natural sound up mixer
  • Dolby Atmos & DTS:X 7.1.4 decoding
  • IMAX Enhanced
  • DTS Virtual:X
  • Dolby Vision compatible
  • 4K (UHD) HDMI2.0a with HDCP2.2
  • 7 HDMI inputs, 3 HDMI outputs, ARC compatible
  • Dirac Live ® for Lexicon room correction
  • Spotify ® Connect enabled
  • Cirrus CS42528 audiophile DAC
  • Class A/B power amplification
  • Ethernet, RS232 and IR control
  • Lexicon AV control app

General Specifications

Continuous power output, per channel 8Ω/4Ω
2 channels driven, 20Hz ‑ 20kHz, <0.02% THD 110W
2 channels driven, 1kHz, 0.2% THD 125W
7 channels driven, 1kHz, 0.2% THD 90W
Residual noise & hum (A-wtd) <0.15mV
Mains voltage 110–120V or 220–240V, 50–60Hz
Power consumption (maximum) 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical) 100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby) <0.5W

Dimensions

W x D (including speaker terminals) x H (including feet) 433 x 425 x 171mm
Weight (net) 15.5kg
Weight (packed) 18.8kg

Audio Interface

Preamplifier outputs
Nominal output level 1V RMS
Output impedance 560Ω
THD+N (20Hz—20kHz) -100dB

Audio Output

Headphone output
Maximum output level into 32Ω 2Vrms
Output impedance <5Ω

Audio Input

Stereo line inputs
Maximum input 4.5V rms
Nominal sensitivity 1V, 2V, 4V (user adjustable)
Input impedance 47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct 100dB/110dB
Frequency response 20Hz—20kHz at 0.2dB

What's in the box?

  • Supplied accessories Mains lead
  • Remote control
  • 2 x AAA batteries
  • Manual
  • DAB/FM aerial
  • Calibration microphone
  • USB sound card
  • E&OE
